• Country
• Switzerland

• Manufacturer / Brand
• Autophon AG (inkl. Téléphonie SA); Solothurn

• Year
• 1975 ??

• Category
• Commercial Transmitter & Receiver (TRX not Amateur)

• Radiomuseum.org ID
• 218850

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Transceiver

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Batteries / addl. power jack / 10-16 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2.5 W (unknown quality)

• from Radiomuseum.org
• Model: Radiovox SE-55K - Autophon AG inkl. Téléphonie

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 221 x 53 x 226 mm / 8.7 x 2.1 x 8.9 inch

• Notes
• Funkgerät RADIOVOX 55, der Autophon AG.

  Systemvorstellung:
  Kompaktausführung: SE 55 K (Kompakt).

  SE 55-08-... 68 - 87,5 MHz,
  SE 55-16-... 146 - 174 MHz,
  SE 55-46-... 400 - 470 MHz,
  1 - 6 Kanäle. 20/25 kHz Kanalabstand. 6 oder 15 W Sendeleistung. 800 Hz Rufton. 5 Ton Selektivruf.

  Die einzelnen Modelle im Detail bitte einzeln listen wenn die konkreten Typensuffixe auch mit Typenschildbild belegbar sind!

• Net weight (2.2 lb = 1 kg)
• 2.5 kg / 5 lb 8.1 oz (5.507 lb)

• Source of data
• - - Manufacturers Literature
