Jolly Transistor 378
Autovox SPA; Roma
- Country
- Italy
- Manufacturer / Brand
- Autovox SPA; Roma
- Year
- 1971 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 220562
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- A31-19W
- Number of Transistors
- 26
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Line / Batteries (any type) / 125; 160; 220; 260 / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Jolly Transistor 378 - Autovox SPA; Roma
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 380 x 260 x 190 mm / 15 x 10.2 x 7.5 inch
- Notes
- Televisore da 12 pollici portatile con maniglia.
Portable 12" TV, with carrying handle.
For the CRT, the schematic shows the designation VA31-319 which is wrong.
- Net weight (2.2 lb = 1 kg)
- 8.7 kg / 19 lb 2.6 oz (19.163 lb)
- Circuit diagram reference
- Schemario TV , Il Rostro
- Author
- Model page created by Raffaele Pedrini. See "Data change" for further contributors.
