RA561

Autovox SPA; Roma

Data
Forum
Pictures
Collections

  • Year
  • 1968 ??
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 159319

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 16
  • Semiconductors
  • Main principle
  • Superhet with RF-stage; ZF/IF 10700/455 kHz
  • Tuned circuits
  • 7 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 7 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: RA561 - Autovox SPA; Roma
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 180 x 52 x 60 mm / 7.1 x 2 x 2.4 inch
  • Notes
  • Ricerca automatica delle stazioni
    Controllo di tono
    Presa per giranastri
  • Net weight (2.2 lb = 1 kg)
  • 1.7 kg / 3 lb 11.9 oz (3.744 lb)
  • Literature/Schematics (1)
  • Selezione Radio-TV Dicembre 1972
  • Author
  • Model page created by Eduard Abfalterer. See "Data change" for further contributors.
