RA-106

• Country
• Italy

• Manufacturer / Brand
• Autovox SPA; Roma

• Year
• 1960–1962

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 80875

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 12AC6 12AD6 12AF6 12DL8

• Number of Transistors
• 1

• Semiconductors
• unknown_tr

• Main principle
• Superhet with RF-stage; ZF/IF 262 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: RA-106 - Autovox SPA; Roma

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 160 x 70 x 120 mm / 6.3 x 2.8 x 4.7 inch

• Notes

• Autoradio per Fiat 600 e 500, Autobianchi Bianchina, Alfa Romeo Dauphine. Prezzo fine 1962 (solo apparecchio): 19.700 Lire. Il transistor è marcato Autovox K 0477.3 mentre su Guida Pratica AR III è indicato come 12M2. Diversi frontalini a seconda della vettura su cui applicare l'autoradio.

  Sintonia ad induttori variabili.

• Price in first year of sale
• 35,800.00 ITL

• Source of data
• Guida Pratica Antique Radio III (2000)

• Mentioned in
• Guida Pratica Antique Radio IV (2001)

• Literature/Schematics (1)
• Pubblicità - Quattroruote Luglio 1960

• Literature/Schematics (2)
• -- Schematic

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
