- Country
- Great Britain (UK)
- Manufacturer / Brand
- Alba (Brand) Balcombe Ltd., ALBA (Radio & Television) Ltd; London
- Year
- 1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 88358
-
- Brand: Alba
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Alba 3841 - Alba Brand Balcombe Ltd., ALBA
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 380 x 450 x 260 mm / 15 x 17.7 x 10.2 inch
- Notes
- 100-120V AC mains option available to order.
- Net weight (2.2 lb = 1 kg)
- 7.2 kg / 15 lb 13.7 oz (15.859 lb)
- Price in first year of sale
- 22.00 pound
- Mentioned in
- Service Charts of Electrical and Radio Trading
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1111)
- Author
- Model page created by Mario Coelho. See "Data change" for further contributors.
