• Country
• Germany

• Manufacturer / Brand
• Bauer, Eugen; Stuttgart

• Year
• 1960 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 114161

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• EF86 EF86 EL84

• Number of Transistors

• Semiconductors
• B300C70

• Main principle
• Audio-Amplification; 3 AF stage(s)

• Wave bands
• - without

• Power type and voltage
• Powered by external power supply or a main unit. / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 4 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: 4 Watt-Lichtton- und Magnetton-Wiedergabeverstärker PV5 T2/2 [4 W] - Bauer, Eugen; Stuttgart

• Shape
• Tablemodel, with any shape - general.

• Notes

• Verstärkerteil des 16-mm-Projektors „BAUER P 5" T 4
  4 Watt-Lichtton- und Magnetton-Wiedergabeverstärker
  für die Wiedergabe von Filmen mit Lichtton- und Magnettonspur.


  Weitere Ausführung vom BAUER 4 Watt-Verstärkern
   für die Wiedergabe von Filmen mit Lichtton-Aufzeichnung: BAUER PV5 L2/2


• Price in first year of sale
• 537.00 DM

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Heribert Jung. See "Data change" for further contributors.
