AE 110

AE 110; Budapesti (ID = 538074) Ampl/Mixer
AE 110; Budapesti (ID = 447615) Ampl/Mixer AE 110; Budapesti (ID = 909040) Ampl/Mixer
AE 110; Budapesti (ID = 909041) Ampl/Mixer AE 110; Budapesti (ID = 909042) Ampl/Mixer
AE 110; Budapesti (ID = 985707) Ampl/Mixer AE 110; Budapesti (ID = 985708) Ampl/Mixer
AE 110; Budapesti (ID = 985709) Ampl/Mixer AE 110; Budapesti (ID = 985710) Ampl/Mixer
Use red slider bar for more.
AE 110; Budapesti (ID = 447615) Ampl/Mixer
Budapesti: AE 110 [Ampl/Mixer] ID = 447615 550x284
Select picture or schematic to display from thumbnails on the right and click for download.
For model AE 110, Budapesti Elektroakusztikai Gyár (BEAG), Budapest:
RÁVILL árjegyzék. 1967.

Country:  Hungary
Manufacturer / Brand:  Budapesti Elektroakusztikai Gyár (BEAG), Budapest
Year: 1965–1967 Category: Audio Amplifier or -mixer
Valves / Tubes 4: ECL86 ECL86 ECC83 EZ81
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 10 W (unknown quality)
from Radiomuseum.org Model: AE 110 - Budapesti Elektroakusztikai Gy
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 285 x 95 x 270 mm / 11.2 x 3.7 x 10.6 inch
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 1'390.00 HUF
Mentioned in Technika, 1966/05
Literature/Schematics (1) RÁVILL Árjegyzék, 1967.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
