EAG Audio Amplifier EA-057
BEAG - Budapesti Elektroakusztikai Gyár; Budapest
- Country
- Hungary
- Manufacturer / Brand
- BEAG - Budapesti Elektroakusztikai Gyár; Budapest
- Year
- 1957
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 223136
- Number of Tubes
- 4
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 20 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: EAG Audio Amplifier EA-057 - BEAG - Budapesti
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 400 x 225 x 125 mm / 15.7 x 8.9 x 4.9 inch
- Notes
- 20 W / 15 Ohm, 50-15000 Hz +/- 3 dB.
- Net weight (2.2 lb = 1 kg)
- 15 kg / 33 lb 0.6 oz (33.04 lb)
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
- Other Models
-
