Koncert Stereo SRS-23W

Koncert Stereo SRS-23W; Budapesti (ID = 745054) Radio Koncert Stereo SRS-23W; Budapesti (ID = 745055) Radio
Koncert Stereo SRS-23W; Budapesti (ID = 1503506) Radio Koncert Stereo SRS-23W; Budapesti (ID = 1504499) Radio
Koncert Stereo SRS-23W; Budapesti (ID = 1504500) Radio Koncert Stereo SRS-23W; Budapesti (ID = 1504504) Radio
Koncert Stereo SRS-23W; Budapesti (ID = 1504505) Radio Koncert Stereo SRS-23W; Budapesti (ID = 1504507) Radio
Koncert Stereo SRS-23W; Budapesti (ID = 1504509) Radio Koncert Stereo SRS-23W; Budapesti (ID = 1504510) Radio
Use red slider bar for more.
Koncert Stereo SRS-23W; Budapesti (ID = 745054) Radio
Budapesti: Koncert Stereo SRS-23W [Radio] ID = 745054 816x537
Select picture or schematic to display from thumbnails on the right and click for download.
For model Koncert Stereo SRS-23W, Budapesti Elektroakusztikai Gyár (BEAG), Budapest:
Thanks for .cruisher.digitaltrip.hu ! Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Budapesti Elektroakusztikai Gyár (BEAG), Budapest
Year: 1965–1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EBF89 ECC83 EM84 ECL82 ECL82
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out 7 W (unknown quality)
from Radiomuseum.org Model: Koncert Stereo SRS-23W - Budapesti Elektroakusztikai Gy
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 1120 x 390 x 450 mm / 44.1 x 15.4 x 17.7 inch
Notes

FM: OIRT.

Overall dimensions: 1120× 754× 450 mm.

Net weight (2.2 lb = 1 kg) 40 kg / 88 lb 1.7 oz (88.106 lb)
Price in first year of sale 6'950.00 HUF
Literature/Schematics (4) Híradástechnikai cikkek kereskedelmi árjegyzéke, BP. 1967

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
