For model Mexico ab 945591, Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim

Country:  Germany
Manufacturer / Brand:  Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
Year: 1957/1958 ? Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 7: ECC85 ECH81 EF85 EBF80 EABC80 EBF80 ECC85
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3.7 W (unknown quality)
from Radiomuseum.org Model: Mexico [ab 945591] - Becker, Max Egon,
Material Metal case
Shape Chassis only or for «building in»
Notes 2-teilig. Normale Endstufe mit EL84; auch mit Gegentakt-Endstufe lieferbar, dann 2× EL84.
Source of data HdB d.Rdf-& Ferns-GrH 1955/56 / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Schematic

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
