AC Bridge BR-8S

AC Bridge BR-8S; Belco, Tokyo (ID = 1497521) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 475514) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 812182) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 812183) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 812184) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 812185) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 1497522) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 1497523) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 1497524) Equipment

AC Bridge BR-8S; Belco, Tokyo (ID = 1497525) Equipment
AC Bridge BR-8S; Belco, Tokyo (ID = 2314011) Equipment AC Bridge BR-8S; Belco, Tokyo (ID = 2314010) Equipment
AC Bridge BR-8S; Belco, Tokyo (ID = 2314012) Equipment AC Bridge BR-8S; Belco, Tokyo (ID = 2314013) Equipment
AC Bridge BR-8S; Belco, Tokyo (ID = 2314014) Equipment AC Bridge BR-8S; Belco, Tokyo (ID = 811962) Equipment
AC Bridge BR-8S; Belco, Tokyo (ID = 811964) Equipment AC Bridge BR-8S; Belco, Tokyo (ID = 388585) Equipment
AC Bridge BR-8S; Belco, Tokyo (ID = 1497519) Equipment AC Bridge BR-8S; Belco, Tokyo (ID = 1497520) Equipment
Use red slider bar for more.
AC Bridge BR-8S; Belco, Tokyo (ID = 2314011) Equipment
Belco, Tokyo: AC Bridge BR-8S [Equipment] ID = 2314011 1400x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model AC Bridge BR-8S, Belco, Tokyo:
sammlung

Country:  Japan
Manufacturer / Brand:  Belco, Tokyo
Year: 1988 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 4: 2SC372 2SC372 2SC372 2SC372
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: AC Bridge BR-8S - Belco, Tokyo
Material Metal case
Dimensions (WHD) 182 x 75 x 128 mm / 7.2 x 3 x 5 inch
Notes L-C-R Bridge with generator 1kHz and three stage measuring amplifier.
Ranges: 0.1-10Ω, 10Ω-5MΩ, 5MΩ-11MΩ, 1µH-100µH, 1mH-111H, 10pF-1nF, 1nF-111µF, 111µF-1110µF, Turn Ratio 1:1/10000 and 1:11100.
Earphone connector provided for listening to the bridge minimum.
Improvement compared to the BR8 model: concentric double potentimeter.
Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Price in first year of sale 279.00 DM
Mentioned in RIM electronic 88

Model page created by Georg Richter. See "Data change" for further contributors.
