Radiobell 537 (537A) 6A7

Radiobell 537 ; Bell Telephone Mfg. (ID = 1117952) Radio
Radiobell 537 ; Bell Telephone Mfg. (ID = 1786762) Radio Radiobell 537 ; Bell Telephone Mfg. (ID = 1058937) Radio
Radiobell 537 ; Bell Telephone Mfg. (ID = 676734) Radio Radiobell 537 ; Bell Telephone Mfg. (ID = 571178) Radio
Radiobell 537 ; Bell Telephone Mfg. (ID = 571179) Radio Radiobell 537 ; Bell Telephone Mfg. (ID = 676737) Radio
Radiobell 537 ; Bell Telephone Mfg. (ID = 676741) Radio Radiobell 537 ; Bell Telephone Mfg. (ID = 676746) Radio
Radiobell 537 ; Bell Telephone Mfg. (ID = 1058546) Radio Radiobell 537 ; Bell Telephone Mfg. (ID = 1058938) Radio
Use red slider bar for more.
Radiobell 537 ; Bell Telephone Mfg. (ID = 1786762) Radio
Bell Telephone Mfg.: Radiobell 537 [Radio] ID = 1786762 933x630
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiobell 537 (537A) 6A7, Bell Telephone Mfg. Co. (Radiobell); Antwerp

Country:  Belgium
Manufacturer / Brand:  Bell Telephone Mfg. Co. (Radiobell); Antwerp
Brand

Radiobell
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 78 75 6B5 Neon_Indicator 80
Main principle Super-Heterodyne (Super in general); ZF/IF 142 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 120; 135; 150; 225; 250 & 0,9 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Radiobell 537 [6A7] - Bell Telephone Mfg. Co.
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes

Codex J.V. AS4736;  Mallory Gitterbatterie.

Price in first year of sale 2'975.00 BFr
Mentioned in Manuel de la Radio 1940, van Cortenberghe ("Radio Schakelingen" (J.G.R. van Dijck))
Literature/Schematics (1) Brans, P.H. Radio Schema's, Antwerpen (1943 deel II)

Model page created by Gidi Verheijen. See "Data change" for further contributors.



All listed radios etc. from Bell Telephone Mfg. Co. (Radiobell); Antwerp
Here you find 273 models, 236 with images and 109 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
