2200C ; Bell Sound Systems; (ID = 1262372) Ampl/Mixer
Bell Sound Systems;: 2200C [Ampl/Mixer] ID = 1262372 736x432
Select picture or schematic to display from thumbnails on the right and click for download.
For model 2200C, Bell Sound Systems; Columbus (OH):
aus ebay, #130714674760, mit Erlaubnis des Verkäufers spiritman68

Country:  United States of America (USA)
Manufacturer / Brand:  Bell Sound Systems; Columbus (OH)
Year: 1955 ? Category: Audio Amplifier or -mixer
Valves / Tubes 7: 6SC7 6SL7 6SN7GT 6SL7 5881 5881 5U4
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 50 - 60Hz; 110 - 120 Volt
Loudspeaker - This model requires external speaker(s).
Power out 20 W (undistorted)
from Radiomuseum.org Model: 2200C - Bell Sound Systems; Columbus
Material Metal case, TUBES VISIBLE
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 16 x 7.625 x 8.75 inch / 406 x 194 x 222 mm
Notes

Mono hi-fidelity amplifier initially sold without the cage.  Later available with either an ivory or brown cage for an additional $7.79.

Price in first year of sale 97.95 $
Literature/Schematics (1) Allied Radio Catalog (Knight) (1955, page 14)

Model page created by Vitor Oliveira. See "Data change" for further contributors.



All listed radios etc. from Bell Sound Systems; Columbus (OH)
Here you find 104 models, 100 with images and 64 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
