For model B-M19b, Beyerdynamic; Heilbronn:
Bild von Manfred K. Schulte.

Country:  Germany
Manufacturer / Brand:  Beyerdynamic; Heilbronn
Year: 1939 Category: Microphone or Pick-up element
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: B-M19b - Beyerdynamic; Heilbronn
Material Metal case
Dimensions (WHD) 65 x 65 x 110 mm / 2.6 x 2.6 x 4.3 inch
Notes Dynamisches Mikrofon, Kugelcharakteristik
Übertragungsbereich 50 bis 12.000 Hz
Empfindlichkeit 0,2 mV/µbar
Impedanz 200 Ohm.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
