HF-TR-Vorsatzgerät 01HE

HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2268847) Radio
HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 238308) Radio HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 238309) Radio
HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184279) Radio HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184286) Radio
HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184287) Radio HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184290) Radio
HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184299) Radio HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184306) Radio
HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184307) Radio HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 2184312) Radio
Use red slider bar for more.
HF-TR-Vorsatzgerät 01HE; Biennophone; Marke (ID = 238308) Radio
Biennophone; Marke: HF-TR-Vorsatzgerät 01HE [Radio] ID = 238308 600x545
Select picture or schematic to display from thumbnails on the right and click for download.
For model HF-TR-Vorsatzgerät 01HE, Biennophone; (Marke)

Country:  Switzerland
Manufacturer / Brand:  Biennophone; (Marke)
alternative name

Sport AG Biel || Velectra AG
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 1: EBF89
Main principle TRF with diode detector
Tuned circuits 1 AM circuit(s)
Wave bands Long Wave and/or Very Low Frequency (VLF).
Details Wired Wireless Receiver (RF!)
Power type and voltage Powered by external power supply or a main unit. / AC 6,3 & DC 200-250 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: HF-TR-Vorsatzgerät 01HE - Biennophone; Marke
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 90 x 80 x 70 mm / 3.5 x 3.1 x 2.8 inch
Notes

Biennophone Type 01HE ist ein Einbau-Modul für den Empfang des schweizer HF-Telefonrundspruchs.

Literature/Schematics (1) -- Schematic

Model page created by Noël Giller. See "Data change" for further contributors.
