Handgenerator-Umformer GU

Handgenerator-Umformer GU; Biennophone; Marke (ID = 226471) Power-S

Handgenerator-Umformer GU; Biennophone; Marke (ID = 226472) Power-S

Handgenerator-Umformer GU; Biennophone; Marke (ID = 226477) Power-S

Handgenerator-Umformer GU; Biennophone; Marke (ID = 226480) Power-S
Handgenerator-Umformer GU; Biennophone; Marke (ID = 226752) Power-S Handgenerator-Umformer GU; Biennophone; Marke (ID = 226753) Power-S
Handgenerator-Umformer GU; Biennophone; Marke (ID = 226754) Power-S Handgenerator-Umformer GU; Biennophone; Marke (ID = 226755) Power-S
Handgenerator-Umformer GU; Biennophone; Marke (ID = 1283309) Power-S Handgenerator-Umformer GU; Biennophone; Marke (ID = 1283310) Power-S
Handgenerator-Umformer GU; Biennophone; Marke (ID = 1283311) Power-S Handgenerator-Umformer GU; Biennophone; Marke (ID = 1283312) Power-S
Handgenerator-Umformer GU; Biennophone; Marke (ID = 1283313) Power-S
Use red slider bar for more.
Handgenerator-Umformer GU; Biennophone; Marke (ID = 226752) Power-S
Biennophone; Marke: Handgenerator-Umformer GU [Power-S] ID = 226752 263x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Handgenerator-Umformer GU, Biennophone; (Marke)

Country:  Switzerland
Manufacturer / Brand:  Biennophone; (Marke)
alternative name

Sport AG Biel || Velectra AG
Year: 1952 Category: Power supply/conditioner or battery or charger
Wave bands - without
Details
Power type and voltage Other, details in remarks or not known.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Handgenerator-Umformer GU - Biennophone; Marke
Material Metal case
Dimensions (WHD) 220 x 320 x 170 mm / 8.7 x 12.6 x 6.7 inch
Notes Stromversorgung der Kleinfunkstation SE200 (Lux); kann entweder von Hand oder mit einem 6-V-Akku betrieben werden.
Daten: Heizspannung 4,2 V/1,6 A; Anodenspannung beim Empfang 90 V/36 mA. Anodenspannung beim Senden 90 V/50 mA und 180 V/60 mA. Kurbeldrehzahl 60-65 U/min.
Net weight (2.2 lb = 1 kg) 17.5 kg / 38 lb 8.7 oz (38.546 lb)
Mentioned in -- Original-techn. papers.

Model page created by Alexander Küffer. See "Data change" for further contributors.
