TV-Schrank 26K223 Ch= Philips KM1L

Biennophone; (Marke)

  • Year
  • 1974
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 239463
    • alternative name: Sport AG Biel || Velectra AG

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 14
  • Number of Transistors
  • 85
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: TV-Schrank 26K223 Ch= Philips KM1L - Biennophone; Marke
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 810 x 692 x 616 mm / 31.9 x 27.2 x 24.3 inch
  • Notes
  • Color-TV mit VHF/UHF-Tuner und 66cm-Bildschirm in Standmöbel mit Falttüren und 2 Frontlautsprechern. Nussbaum hochglanz. Programmspeicher mit 12 Leuchttasten. PAL und SECAM.

  • Net weight (2.2 lb = 1 kg)
  • 64 kg / 140 lb 15.5 oz (140.969 lb)
  • Price in first year of sale
  • 4,450.00 SFr
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
