Verbier 6303 / 03-HE

Verbier 6303 / 03-HE; Biennophone; Marke (ID = 1489374) Radio

Verbier 6303 / 03-HE; Biennophone; Marke (ID = 1489375) Radio

Verbier 6303 / 03-HE; Biennophone; Marke (ID = 1489376) Radio

Verbier 6303 / 03-HE; Biennophone; Marke (ID = 1489378) Radio

Verbier 6303 / 03-HE; Biennophone; Marke (ID = 1489377) Radio
Verbier 6303 / 03-HE; Biennophone; Marke (ID = 114511) Radio Verbier 6303 / 03-HE; Biennophone; Marke (ID = 114512) Radio
Verbier 6303 / 03-HE; Biennophone; Marke (ID = 114513) Radio
Use red slider bar for more.
Verbier 6303 / 03-HE; Biennophone; Marke (ID = 114511) Radio
Biennophone; Marke: Verbier 6303 / 03-HE [Radio] ID = 114511 897x556
Select picture or schematic to display from thumbnails on the right and click for download.
For model Verbier 6303 / 03-HE, Biennophone; (Marke)

Country:  Switzerland
Manufacturer / Brand:  Biennophone; (Marke)
alternative name

Sport AG Biel || Velectra AG
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECC85 ECH81 EBF89 ECL86
Semiconductors (the count is only for transistors) OA79 OA79
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Wired Wireless Receiver (RF!)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Verbier 6303 / 03-HE - Biennophone; Marke
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 302 x 166 x 181 mm / 11.9 x 6.5 x 7.1 inch
Notes

Siehe auch technisch identisches Modell Sottens 6303 mit anderem Gehäuse.

Price in first year of sale 278.00 SFR
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original-techn. papers.

Model page created by Markus Meier. See "Data change" for further contributors.



All listed radios etc. from Biennophone; (Marke)
Here you find 493 models, 267 with images and 300 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
