Operatic 62RC

Operatic 62RC; Bland Radio Ltd; (ID = 2081042) Radio
Use red slider bar for more.
Operatic 62RC; Bland Radio Ltd; (ID = 2081042) Radio
Bland Radio Ltd;: Operatic 62RC [Radio] ID = 2081042 667x796
Select picture or schematic to display from thumbnails on the right and click for download.
For model Operatic 62RC, Bland Radio Ltd; Adelaide:
Operatic 61RG and 62RC from an advert in Mingay's Radio Diagram and I.F. Index 1936-1948.

Country:  Australia
Manufacturer / Brand:  Bland Radio Ltd; Adelaide
Brand

Operatic
Year: 1947–1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EK32 6U7G 6SQ7GT 6SN7GT 6V6GT 6V6GT 5Y3GT
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 220-260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
Power out 10 W (unknown quality)
from Radiomuseum.org Model: Operatic 62RC - Bland Radio Ltd; Adelaide
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes This model uses a Garrard changer.
Circuit diagram reference Australian Official Radio Service Manual Vol. VI
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
