For model ACR 925 7.632.903, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1972/1973 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 14:
Details Cassette-Recorder or -Player
Power type and voltage Storage and/or dry batteries / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 10 W (unknown quality)
from Radiomuseum.org Model: ACR 925 7.632.903 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179 x 155 x 50 mm / 7 x 6.1 x 2 inch
Notes

Das Blaupunkt Autotonbandgerät ACR 925 kann unabhängig von einem Autoradio an 12 Volt, Minus an Masse, betrieben werden und arbeitet als Stereo-Wiedergabe-Gerät mit eingebauter Endstufe.

2 x 5 Watt.

External source of data Erb
Source of data Handbuch VDRG 1972/1973
