ACR 930 7.607.708.000

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561634) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561636) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561637) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561638) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561639) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561640) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561641) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561642) R-Player

ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561643) R-Player
ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561644) R-Player
Use red slider bar for more.
ACR 930 7.607.708.000; Blaupunkt Ideal, (ID = 561644) R-Player
Blaupunkt Ideal,: ACR 930 7.607.708.000 [R-Player] ID = 561644 748x421
Select picture or schematic to display from thumbnails on the right and click for download.
For model ACR 930 7.607.708.000, Blaupunkt (Ideal), Berlin, später Hildesheim:
Bild aus Blaupunkt Service Unterlagen

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1980 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 16:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: ACR 930 7.607.708.000 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179 x 50 x 146 mm / 7 x 2 x 5.7 inch
Notes ICs: 9
Stereo-Tapedeck ACR930 mit Leistungsverstärker; Nennleistung: 4× 15 W (Sinus); Übertragungsbereich: Cassettenteil 40-15000 Hz.
Mentioned in Original Blaupunkt Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
