ACR 931 7.607.709.010; Blaupunkt Ideal, (ID = 1773766) R-Player
Blaupunkt Ideal,: ACR 931 7.607.709.010 [R-Player] ID = 1773766 1200x489
Select picture or schematic to display from thumbnails on the right and click for download.
For model ACR 931 7.607.709.010, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1980 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 17:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: ACR 931 7.607.709.010 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179 x 50 x 146 mm / 7 x 2 x 5.7 inch
Notes ICs: 10
Stereo Tapedeck ACR931 mit Leistungsverstärker; Nennleistung: 4× 15 W (Sinus); Übertragungsbereich Cassettenteil: 40-15000 Hz.
Mentioned in Original Blaupunkt Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
