Amazonas 7.629.770

Amazonas 7.629.770; Blaupunkt Ideal, (ID = 968986) Radio
Amazonas 7.629.770; Blaupunkt Ideal, (ID = 328566) Radio Amazonas 7.629.770; Blaupunkt Ideal, (ID = 1608466) Radio
Use red slider bar for more.
Amazonas 7.629.770; Blaupunkt Ideal, (ID = 328566) Radio
Blaupunkt Ideal,: Amazonas 7.629.770 [Radio] ID = 328566 353x281
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amazonas 7.629.770, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1970/1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 19:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Amazonas 7.629.770 - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1125 x 765 x 345 mm / 44.3 x 30.1 x 13.6 inch
Notes Rundfunk-Spezialchassis = 7.629.100, Vollstereo, NF-Verstärker mit zwei Endstufen je 3,5 W;
Phono-Chassis = PE 2001.
Net weight (2.2 lb = 1 kg) 35 kg / 77 lb 1.5 oz (77.093 lb)
External source of data Erb
Source of data Handbuch VDRG 1970/1971
