Ancona CR24 7.643.754.013

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796160) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796162) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796163) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796164) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796165) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796166) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796168) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796169) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796171) Car Radio

Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1796172) Car Radio
Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1855777) Car Radio Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1855778) Car Radio
Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1855779) Car Radio
Use red slider bar for more.
Ancona CR24 7.643.754.013; Blaupunkt Ideal, (ID = 1855777) Car Radio
Blaupunkt Ideal,: Ancona CR24 7.643.754.013 [Car Radio] ID = 1855777 1200x580
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ancona CR24 7.643.754.013, Blaupunkt (Ideal), Berlin, später Hildesheim:
Q: Blaupunkt, Service-Unterlagen

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1994 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) Semiconductors present. TDA1575T TDA1072 TDA4220 TDA2005
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Ancona CR24 7.643.754.013 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Mentioned in -- Original-techn. papers. (Schaltbild 3 D94 240 018 Kr 07/94)

Model page created by Hans Völkening. See "Data change" for further contributors.
