Automatic Code Timer ACT-300

Blaupunkt (Ideal), Berlin, später Hildesheim

  • Year
  • 1989 ?
  • Category
  • Miscellaneous (Other, Various) - see notes
  • Radiomuseum.org ID
  • 222316
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Dry Batteries / 4 x 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Automatic Code Timer ACT-300 - Blaupunkt Ideal, Berlin,
  • Dimensions (WHD)
  • 32 x 23 x 157 mm / 1.3 x 0.9 x 6.2 inch
  • Notes
  • Der Automatic Code Timer "ACT-300" von Blaupunkt ist ein Strichcode/Barcode-Lesegerät und IR-Sender zum Übertragen der eingelesenen Daten für zeitversetzte Aufnahmen verschiedener Blaupunkt/Panasonic Video-Recorder.
  • Net weight (2.2 lb = 1 kg)
  • 0.052 kg / 0 lb 1.8 oz (0.115 lb)
  • Author
  • Model page created by Jürgen Küting. See "Data change" for further contributors.
