Ballett 23 100; Blaupunkt Ideal, (ID = 1792789) Radio
Blaupunkt Ideal,: Ballett 23 100 [Radio] ID = 1792789 933x673
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ballett 23 100, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1963–1965 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: ECC85 EBF89 ECL86
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Ballett 23 100 - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 344 x 214 x 152 mm / 13.5 x 8.4 x 6 inch
Notes Dioden: 2× OA79
Net weight (2.2 lb = 1 kg) 4.6 kg / 10 lb 2.1 oz (10.132 lb)
Price in first year of sale 288.00 DM
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1963/1964
