Bamberg CR 7.634.934 ab 5480001; Blaupunkt Ideal, (ID = 1568693) Car Radio
Blaupunkt Ideal,: Bamberg CR 7.634.934 ab 5480001 [Car Radio] ID = 1568693 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Bamberg CR 7.634.934 ab 5480001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1978 ?? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 39:
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Bamberg CR 7.634.934 ab 5480001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Notes Dieses Autoradio entspricht dem Gerät Bamberg CR 7.634.932 bis auf die ASU, die im 934er Gerät im Verbindungskabel zwischen Grundgerät und NF-Verstärker zusätzlich eingefügt ist.
Mentioned in Original Blaupunkt Service Unterlagen
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Josef Pilz. See "Data change" for further contributors.
