Diva 7.659.400; Blaupunkt Ideal, (ID = 630971) Radio
Blaupunkt Ideal,: Diva 7.659.400 [Radio] ID = 630971 736x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Diva 7.659.400, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1969–1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF106 AF121 AF126 BF341 BF342 BF343 BC168 BC262 AC187 AC188
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6×1,5; 2×4,5; 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Diva 7.659.400 - Blaupunkt Ideal, Berlin,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 247 x 159 x 71 mm / 9.7 x 6.3 x 2.8 inch
Notes Netzbetrieb mit zusätzlichem Netzteil möglich.
Im Gerät können wahlweise 2 Flachbatterien 4,5 Volt, 6 Babyzellen je 1,5 Volt oder ohne Batteriehalter eine 9 Volt Blockbatterie (66×52×81mm) verwendet werden. Aufpreis für Netzteil DM 77.-
Net weight (2.2 lb = 1 kg) 1.630 kg / 3 lb 9.4 oz (3.59 lb)
Price in first year of sale 150.00 DM
Collectors' prices
Source of data Handbuch VDRG 1969/1970 / Radiokatalog Band 1, Ernst Erb
Mentioned in Handbuch VDRG 1970/1971
Literature/Schematics (1) -- Original-techn. papers.
