• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1967/1968

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 856

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• AF124 AF125 AF126 AF126 AF126 AC127 AC128 AC128 AC127 AC128 AA119

• Main principle
• Superheterodyne (common); ZF/IF 452 or 460/10700 kHz

• Tuned circuits
• 5 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / C: 4 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Dixie 7.657.200 [ab Y 210001] - Blaupunkt Ideal, Berlin,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 205 x 110 x 50 mm / 8.1 x 4.3 x 2 inch

• Notes

• Dioden: 5x AA119, Diodentype nur einmal gelistet..

  Netzbetrieb mit zusätzlichem Netzteil möglich.

  Produktion Philips (Wetzlar) für Blaupunkt.
  Siehe auch Nanette de Luxe 12RL183.

• Net weight (2.2 lb = 1 kg)
• 0.8 kg / 1 lb 12.2 oz (1.762 lb)

• Source of data
• Handbuch VDRG 1967/1968 / Radiokatalog Band 1, Ernst Erb

• Literature/Schematics (1)
• -- Original-techn. papers. (Service-Manual KDB 976-402, Serie Y)

• Literature/Schematics (2)
• - - Manufacturers Literature (Produkt-Katalog '67)
