Dixie 7.658.200 ab Nr. Z 740001

Dixie 7.658.200; Blaupunkt Ideal, (ID = 335149) Radio

Dixie 7.658.200; Blaupunkt Ideal, (ID = 335151) Radio
Dixie 7.658.200; Blaupunkt Ideal, (ID = 98856) Radio Dixie 7.658.200; Blaupunkt Ideal, (ID = 866197) Radio
Dixie 7.658.200; Blaupunkt Ideal, (ID = 866199) Radio Dixie 7.658.200; Blaupunkt Ideal, (ID = 1441240) Radio
Dixie 7.658.200; Blaupunkt Ideal, (ID = 1441241) Radio Dixie 7.658.200; Blaupunkt Ideal, (ID = 1441242) Radio
Dixie 7.658.200; Blaupunkt Ideal, (ID = 1441243) Radio Dixie 7.658.200; Blaupunkt Ideal, (ID = 1608000) Radio
Use red slider bar for more.
Dixie 7.658.200; Blaupunkt Ideal, (ID = 98856) Radio
Blaupunkt Ideal,: Dixie 7.658.200 [Radio] ID = 98856 495x351
Select picture or schematic to display from thumbnails on the right and click for download.
For model Dixie 7.658.200 ab Nr. Z 740001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1969/1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF106 AF121 AF126 AF121 BF243 BC148 AC122 AC141 AC142
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.3 W (unknown quality)
from Radiomuseum.org Model: Dixie 7.658.200 [ab Nr. Z 740001] - Blaupunkt Ideal, Berlin,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 203 x 103 x 51 mm / 8 x 4.1 x 2 inch
Notes Netzbetrieb mit zusätzlichem Netzteil möglich.
Batterien vom Typ C entspr. "Baby".
Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Source of data Handbuch VDRG 1969/1970 / Radiokatalog Band 1, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.
