Blaupunkt Ideal,: Emden ab X 1120001 [Car Radio] ID = 2394538 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Emden ab X 1120001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1966/1967 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 10: AF106 AF106 AF126 AF126 AF138 AF137 AC126 BC108 AD148 AD148 AA112 SIS20 0,7St60 Z1,5 Z4B4,3
Main principle Superheterodyne (common); ZF/IF 460 or 452/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6/12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Emden ab X 1120001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 42 x 150 mm / 7.1 x 1.7 x 5.9 inch
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Mentioned in KDB 961-198
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Richard Winter. See "Data change" for further contributors.
