For model Essen 7.631.340 / 341 ab 1100001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1971 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 13: AF106 BF255 BF343 BF254 AF201 AF201 BF254 BF343 BC238 BC238 BC328 AD156 AD157
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Essen 7.631.340 / 341 ab 1100001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179 x 42 x 116 mm / 7 x 1.7 x 4.6 inch
Notes Das Blaupunkt Autoradio Essen 7.631.340 hat eine TB-Buchse für ein ACR-Gerät. Zum Betrieb einer Automatik-Antenne ist der Anschluß der Steuerleitung links neben der Batterieklemme.
Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)
Literature/Schematics (1) -- Original-techn. papers. (Dániel József, Autórádiók szervizkönyve, Bp. 1988.)
