For model Essen ab X 1183001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1967 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 12: AF106 AF106 AF126 AF126 AF126 AF121 AF121 AC151 or. AC125 AC125 or. AC151 AC153 or. AC128 AD148 AD148 AA112 SIS20 Z4B4,3 1,4-St10 E45C50
Main principle Superheterodyne (common); ZF/IF 460 or 452/10700 kHz; 4 AF stage(s)
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6/12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Essen ab X 1183001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 178 x 50 x 147 mm / 7 x 2 x 5.8 inch
Notes

AM ZF 452 kHz nur bei besonderer Kennzeichnung.
Diode AA112 5 mal vorhanden, zusätzlich 2 Stabilisatoren 1,4St10 und E45C50

Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Literature/Schematics (1) -- Original-techn. papers.
