Genua 7.629.220

Genua 7.629.220; Blaupunkt Ideal, (ID = 85355) Radio

Genua 7.629.220; Blaupunkt Ideal, (ID = 1691844) Radio

Genua 7.629.220; Blaupunkt Ideal, (ID = 1691845) Radio

Genua 7.629.220; Blaupunkt Ideal, (ID = 1691846) Radio
Genua 7.629.220; Blaupunkt Ideal, (ID = 1162022) Radio Genua 7.629.220; Blaupunkt Ideal, (ID = 85354) Radio
Genua 7.629.220; Blaupunkt Ideal, (ID = 1162023) Radio Genua 7.629.220; Blaupunkt Ideal, (ID = 1162024) Radio
Genua 7.629.220; Blaupunkt Ideal, (ID = 1367574) Radio Genua 7.629.220; Blaupunkt Ideal, (ID = 1367575) Radio
Genua 7.629.220; Blaupunkt Ideal, (ID = 1608458) Radio
Use red slider bar for more.
Genua 7.629.220; Blaupunkt Ideal, (ID = 1162022) Radio
Blaupunkt Ideal,: Genua 7.629.220 [Radio] ID = 1162022 873x445
Select picture or schematic to display from thumbnails on the right and click for download.
For model Genua 7.629.220, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1969–1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: AF106 AF121 AF126 AF201 AF201 BF343 BC108 AC151 AC187 AC188 AD161
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Genua 7.629.220 - Blaupunkt Ideal, Berlin,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 510 x 120 x 168 mm / 20.1 x 4.7 x 6.6 inch
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1970/1971


All listed radios etc. from Blaupunkt (Ideal), Berlin, später Hildesheim
Here you find 3089 models, 2733 with images and 2111 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
