For model Granada 3D 2330 (USA), Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1956/1957 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6AQ8 6AB4 6AJ8 6DA6 6BR5 6T8 6BQ5
Semiconductors (the count is only for transistors) B250C100
Main principle Superhet with RF-stage; ZF/IF 460/10700 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 155; 220; 240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Granada 3D 2330 - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes The Blaupunkt Model Granada 2330 is an AC operated FM-BC-SW 7 Tube Receiver.
Supplier: N. Pickens Import Co., 31 East 14th Street, New York 3, N. Y.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 10-58, Set 418, Folder 4)

Model page created by Egon Penker. See "Data change" for further contributors.
