For model Granada 24 400, Blaupunkt (Ideal), Berlin, später Hildesheim:
Blaupunkt Granada 24400 front

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EAF801 ECL86 EM87 EAM86 ECL86
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Granada 24 400 - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 610 x 340 x 220 mm / 24 x 13.4 x 8.7 inch
Notes KW-Lupe, dreh- und abschaltbare Ferritantenne, Stereo-Decoder (mit ECC81) eingebaut, Stereo-NF-Verstärker mit 2 Endstufen je 4 W.
Net weight (2.2 lb = 1 kg) 11.6 kg / 25 lb 8.8 oz (25.551 lb)
Price in first year of sale 650.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965
