Hamburg ab X 776001; Blaupunkt Ideal, (ID = 2383596) Car Radio
Blaupunkt Ideal,: Hamburg ab X 776001 [Car Radio] ID = 2383596 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hamburg ab X 776001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1966/1967 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 10: AF126 AF126 AF126 AF121 AF127 AC126 or. AC125 AC125 or. AC151 AC153 or. AC128 AD148 AD148 AA112 SIS20 XZ868/25x E45C50
Main principle Superheterodyne (common); ZF/IF 460 or 452 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Hamburg ab X 776001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 176 x 50 x 158 mm / 6.9 x 2 x 6.2 inch
Notes Halbleiter in der NF Stufe wahlweise auch AC125 AC151 AC128
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 249.00 DM
External source of data erb
Source of data Handbuch VDRG 1965/1966
Mentioned in Handbuch VDRG 1966/1967
Literature/Schematics (1) -- Original-techn. papers.
