• Year
  • 1986 ??
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 155598
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 8 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Hamburg M 16 7.645.519.010 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 179 x 44 x 132 mm / 7 x 1.7 x 5.2 inch
  • Notes
  • 2 IC; TDA 1072, TDA 2003, 2xLW und 4xMW.
  • Mentioned in
  • Original Blaupunkt Service Unterlagen
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
