Lido L 7.654.310

Lido L 7.654.310; Blaupunkt Ideal, (ID = 25965) Radio

Lido L 7.654.310; Blaupunkt Ideal, (ID = 1698851) Radio

Lido L 7.654.310; Blaupunkt Ideal, (ID = 1698852) Radio

Lido L 7.654.310; Blaupunkt Ideal, (ID = 1698853) Radio

Lido L 7.654.310; Blaupunkt Ideal, (ID = 1698854) Radio

Lido L 7.654.310; Blaupunkt Ideal, (ID = 1698855) Radio
Lido L 7.654.310; Blaupunkt Ideal, (ID = 25966) Radio Lido L 7.654.310; Blaupunkt Ideal, (ID = 82353) Radio
Lido L 7.654.310; Blaupunkt Ideal, (ID = 487470) Radio
Use red slider bar for more.
Lido L 7.654.310; Blaupunkt Ideal, (ID = 25966) Radio
Blaupunkt Ideal,: Lido L 7.654.310 [Radio] ID = 25966 933x613
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lido L 7.654.310, Blaupunkt (Ideal), Berlin, später Hildesheim:
Bild aus Serviceunterlagen Blaupunkt

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1974/1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 12:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: Lido L 7.654.310 - Blaupunkt Ideal, Berlin,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 160 x 62 mm / 11 x 6.3 x 2.4 inch
Notes
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Source of data Katalog RFP 1974 / Radiokatalog Band 1, Ernst Erb
