Ludwigshafen 7.632.320; Blaupunkt Ideal, (ID = 2383974) Car Radio
Blaupunkt Ideal,: Ludwigshafen 7.632.320 [Car Radio] ID = 2383974 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ludwigshafen 7.632.320, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1972 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 9: BF255 BF254 BC148 BSW73 AD156 AD157
Main principle Super-Heterodyne (Super in general); ZF/IF 460/452 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Ludwigshafen 7.632.320 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 153 x 38 x 92 mm / 6 x 1.5 x 3.6 inch
Notes Halbleiter teilweise mehrfach vorhanden.
Net weight (2.2 lb = 1 kg) 0.7 kg / 1 lb 8.7 oz (1.542 lb)
Mentioned in -- Original-techn. papers.
