Mainamplifier artech MA - 5890 7 628 320
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1988 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 255061
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220/240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 260 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Mainamplifier artech MA - 5890 7 628 320 - Blaupunkt Ideal, Berlin,
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 443 x 136 x 370 mm / 17.4 x 5.4 x 14.6 inch
- Notes
-
HiFi Vollverstärker.
- Net weight (2.2 lb = 1 kg)
- 11.2 kg / 24 lb 10.7 oz (24.67 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by a member from D. See "Data change" for further contributors.
