• Year
  • 1976–1978
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 119768
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 53
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 8 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Mainz CR 7.636.982.010 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 179 x 43 x 158 mm / 7 x 1.7 x 6.2 inch
  • Notes
  • 4 Dickschicht-Schaltungen; 1 Dickschicht-Hybrid-Filter.
    Ausgangsleistung: 2× 5 W.
  • Price in first year of sale
  • 650.00 DM
  • Mentioned in
  • Funkschau (18/1975, S. 107, 108, 109)
  • Literature/Schematics (1)
  • -- Schematic
  • Author
  • Model page created by Heinz LUCAS. See "Data change" for further contributors.
