Mannheim 7.637.030 ab Y 1050001; Blaupunkt Ideal, (ID = 2384004) Car Radio
Blaupunkt Ideal,: Mannheim 7.637.030 ab Y 1050001 [Car Radio] ID = 2384004 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mannheim 7.637.030 ab Y 1050001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1967/1968 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 10: AF106 AF106 AF126 AF126 AF201 AF201 AC126 BC108 AC153 AC153 AA112 SIS20 Z1,5 0,7St60
Main principle Superheterodyne (common); ZF/IF 460 or 452/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Mannheim 7.637.030 ab Y 1050001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179 x 42 x 116 mm / 7 x 1.7 x 4.6 inch
Notes Halbleiter teilweise mehrfach vorhanden.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Price in first year of sale 248.00 DM
External source of data erb
Source of data Handbuch VDRG 1967/1968
Literature/Schematics (1) -- Original-techn. papers.
