Melbourne MR 23 7.643.588.010; Blaupunkt Ideal, (ID = 613301) Car Radio
Blaupunkt Ideal,: Melbourne MR 23 7.643.588.010 [Car Radio] ID = 613301 914x302
Select picture or schematic to display from thumbnails on the right and click for download.
For model Melbourne MR 23 7.643.588.010, Blaupunkt (Ideal), Berlin, später Hildesheim:
Bild aus Blaupunkt Service Unterlagen

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1983 ?? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 23:
Main principle Super-Heterodyne (Super in general); ZF/IF 510/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 20 W (unknown quality)
from Radiomuseum.org Model: Melbourne MR 23 7.643.588.010 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 52 x 160 mm / 7.1 x 2 x 6.3 inch
Notes 6 IC; 2x10 Watt Musikleistung an 2 Ohm.
Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Mentioned in Original Blaupunkt Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
