München III TR (3TR) ab E 990001

Blaupunkt (Ideal), Berlin, später Hildesheim

  • Year
  • 1961/1962
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 24082
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Number of Transistors
  • 3
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12; 24 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 12 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: München III TR ab E 990001 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Notes
  • Omnibus-Übertragungsanlage, bestehend aus Empfängerteil (Stuttgart TR Serie E ohne Wandler und Endstufe), Bedienungsteil, Leistungsverstärker mit Transistor-Gleichspannungswandler für die gemeinsame Stromversorgung. Anschluss für 7 LS (5 Ohm).

  • Price in first year of sale
  • 598.00 DM
  • External source of data
  • Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
