Münster Arimat 7.636.623.010

Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2526272) Car Radio

Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2526273) Car Radio

Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2526274) Car Radio

Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2526275) Car Radio

Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2526276) Car Radio
Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2387312) Car Radio Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2387314) Car Radio
Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2387315) Car Radio Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 415870) Car Radio
Use red slider bar for more.
Münster Arimat 7.636.623.010; Blaupunkt Ideal, (ID = 2387312) Car Radio
Blaupunkt Ideal,: Münster Arimat 7.636.623.010 [Car Radio] ID = 2387312 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Münster Arimat 7.636.623.010, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1977/1978 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 21:
Main principle Superheterodyne (common)
Tuned circuits 7 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Münster Arimat 7.636.623.010 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 179 x 43 x 107 mm / 7 x 1.7 x 4.2 inch
Notes ICs: 2; Dickschichtschaltungen: 3.
Eingebauter Verkehrsfunk-Decoder.
Source of data Handbuch VDRG 1977/1978

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
