Münster ASU 7.636.620.010 ab 600 001

Blaupunkt (Ideal), Berlin, später Hildesheim

  • Year
  • 1976 ?
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 149336
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 19
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Tuned circuits
  • 5 AM circuit(s)     5 FM circuit(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Münster ASU 7.636.620.010 [ab 600 001] - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 179 x 43 x 107 mm / 7 x 1.7 x 4.2 inch
  • Notes
  • 1 IC; je 2 Keramikfilter in der FM-ZF und AM-ZF, 3-Kreis Variometerabstimmung. 5 Omnimat-Speichertasten für 3x UKW und 2x MW. UKW mit automatischer Störunterdrückung (ASU).

  • Mentioned in
  • Original Blaupunkt Service Unterlagen
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
