Ostia 7.622.280; Blaupunkt Ideal, (ID = 147708) Radio

Ostia 7.622.280; Blaupunkt Ideal, (ID = 147709) Radio

Ostia 7.622.280; Blaupunkt Ideal, (ID = 147710) Radio
Ostia 7.622.280; Blaupunkt Ideal, (ID = 147701) Radio Ostia 7.622.280; Blaupunkt Ideal, (ID = 165731) Radio
Use red slider bar for more.
Ostia 7.622.280; Blaupunkt Ideal, (ID = 147701) Radio
Blaupunkt Ideal,: Ostia 7.622.280 [Radio] ID = 147701 933x376
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ostia 7.622.280, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1972/1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Ostia 7.622.280 - Blaupunkt Ideal, Berlin,
Material Plastics (no bakelite or catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 510 x 120 x 168 mm / 20.1 x 4.7 x 6.6 inch
Notes Transistoren: AF106, AF121, AF126, 3× AF201, BC238, BC308, AC194, AC193.
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
External source of data Erb
Source of data Handbuch VDRG 1972/1973
