Ostia 7.622.230; Blaupunkt Ideal, (ID = 1617537) Radio
Blaupunkt Ideal,: Ostia 7.622.230 [Radio] ID = 1617537 932x372
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ostia 7.622.230, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1973 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 7 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: Ostia 7.622.230 - Blaupunkt Ideal, Berlin,
Shape Tablemodel, with any shape - general.
Notes Transistoren: AF106, AF121, AF126, 3× AF201, BC238, BC308, AC194, AC193; Dioden 3× AA112; Gleichrichter: B30C300.
Mentioned in -- Original-techn. papers.

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
