For model STG-1291 7.629.400 ab 385001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1969/1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 34:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     13 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: STG-1291 7.629.400 [ab 385001] - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 560 x 160 x 200 mm / 22 x 6.3 x 7.9 inch
Notes Vollstereo, NF-Verstärker mit zwei Endstufen je 10 W (Sinus).
Net weight (2.2 lb = 1 kg) 7.6 kg / 16 lb 11.8 oz (16.74 lb)
External source of data erb
Source of data Handbuch VDRG 1969/1970
